S3800E Series Closed-loop vector control - High performance:  Control of asynchronous motor and synchronous motor are implemented through the high-performance current vector control technology.
Overload capacity 60s for 150% of the rated current, 3s for 180%( 120%) of the rated current.
Ramp mode: Straight-line ramp; S-curve ramp; Four groups of acceleration/deceleration time with the range of 0.0–6500.0s



V/F control

Control mode

Sensorless flux vector control (VC)

Cloed-loop vector control(CVC)

Vextor control :0~320Hz

Maximum frequency

V/F control :0~3200Hz

Dgital setting :0.01Hz

Input frequency esolution

Analog setting :0.025% of maximum frequency

G type :0.5Hz/150%; 0 Hz/ 180%(CLVC)

Startup torque

P type :0.5Hz/100%


Speed range


Speed stability accuracy


±0.5%(SFVC)   ± 0.02%(CLVC)

Torque control accuracy


Overload capacity

G type : 60s for 150% of the rated current, 3s for 180% of the rated current

P type : 60s for 120% of the rated current, 3s for 150% of the rated curren

Torque boost

Auto boost

Customized boost 0.1%-30.0%

V/F curve

Multi-point curve

N-power V/F curve (1.2 power ,1.4 power,1.6 power,1.8power,square )

V/F separation

Two types :complete separation ; half separation

Ramp mode

Straight-line ramp

S-curve ramp

Four groups of acceleration /deceleration time with the range of 0.0.-6500s

DC braking

DC braking frequency :0.00HZ to maximun frequency

Braking time :0.0~100.0s

Braking action current value :0.0%- 100.0%

JOG control

JOG frequency range :0.00~ 50.00HZ

JOG acceleration /deceleration time :0.0~ 6500.0s

Onboard multiple preset speeds

It implements up to 16 speeds via the simple PLC function or combination of terminal states

Onboard PID

It realizes process-controlled closed loop control system easily

Auto voltage Regulation (AVR)

It can keep constant output voltage automatically when the mains voltage changes.

Overvoltage /Overcurrent stall control

The current and voltage are limited automatically during the running process so as to avoid frequenct tripping due to overvoltage /over current

Torque limit and control

It can limit torque automatically and prevent frequent over current tripping during the running process .Torque control can be implemented in the CVC mode

Support for the multiple PG card

Support for rotating transformer PD card , differential input PG card, resolver PG card and OC input PG card

Power dip ride through

Reduction so that the AC drive can continue to run for a short time

Rapid current limit

It helps to avoid frequent over current faults of the AC drive

High performance

Control of asynchronous motor and synchronous motor are implemented through the high -performance current vector control technology .

Timing control

Time range : 0.0~ 6500.0  mintes

Communication Methods


Protection mode

Motor short -circuit detection at power -on , input/output phase loss protection ,over current protection, overvoltage protection, under voltage protection , overheat protection and overload protection

Installtion Location

Indoor , free from direct sunlight , dust , corrosive gas, combustible gas, oil smol, vapour , drip or salt


Lower than 1000m

Ambient temperature

-10-40de-rated if the ambient temperature is between 40 and 50

Storage temperture
